The plastic injection molding process can cost anywhere from $3,000 to $100,000 or more. Simple molds are typically in the $3,000 to $6,000 range while the price for large, more complex, high-production, or multi-cavity molds can cost $25,000 to $50,000 or more. Considering all the variables involved will help determine the overall injection mold cost.
It is very important to weigh the cost of the mold against the number of parts being produced. Higher production numbers will lower the final per-piece cost of each part as the total injection mold cost can be spread out over hundreds or thousands of parts. While the upfront cost for injection molding can be significant, it is still the fastest, most economical way to produce large quantities of plastic parts.
The majority of the cost for plastic injection molding is in the machining of the mold. The first and foremost factor is the size, followed by the complexity of the mold. Large, complex molds cost more than smaller, simple molds.
The type of mold will also determine price – prototype molds will cost less than molds used for production runs. Molds built specifically for long production runs will be more expensive, as they need to be made of high-strength steel that can stand up to repeated use.
Another factor to consider is the number of injection cavities machined into the mold. High-production molds can have multiple, identical injection cavities, and they are typically referred to as muti-cavity molds. Similarly, “family” molds are molds that have two or more cavities that are similar but not identical.
Plastic injection molds are typically manufactured from either steel or aluminum, each offering distinct advantages.
Aluminum molds are generally less expensive upfront and dissipate heat more efficiently than steel, which can reduce cycle times and improve overall production efficiency. However, aluminum’s lower initial cost comes with trade-offs in durability. Aluminum molds wear out more quickly and cannot be easily repaired or modified.
Steel injection molds, while slightly more expensive initially, offer significantly greater durability and longevity. Their extended lifespan ultimately lowers the per-part cost, making them the preferred choice for production runs. Steel molds are better able to withstand the high heat and pressure of injection molding and can be repaired or modified through welding or reworking if design changes or maintenance are required.
Fathom uses only high-quality, pre-hardened steel for injection mold tooling. Although steel molds may involve a higher upfront investment, they provide superior durability, reliability, and long-term cost savings, delivering greater value to customers over the life of the tool.
A wide range of thermoplastic resins with varying properties can be used in the injection molding process, and material selection plays a major role in overall mold and part cost. Choosing the appropriate plastic resin depends on the functional requirements of the finished part, including performance, appearance, and environmental exposure.
Plastic resin costs typically range from $2 to $20 per pound, depending on the material and its specialized properties. The amount of resin used per injection is influenced by mold size, part geometry, and overall complexity. Certain material characteristics can increase resin cost, including:
Parts that do not require these enhanced properties can often be produced using lower-cost resins, resulting in significant material cost savings without compromising functionality.
A business owner or project manager will seek out several injection molding quotes from competing companies. It is important to know the details behind the price since each mold manufacturer may use a different approach.
Customers should ask about the mold material and how it will be machined. Conventional machining can be slow and expensive. Molds made with Computer Numerical Control (CNC) machining or Electrical Discharge Machining (EDM) can be produced much quicker and with a higher degree of detail.
Fathom offers an online quote system for custom plastic injection molding, CNC machining, or urethane casting projects. There is no software to download – just upload the CAD model to the online portal and select the desired options like part quantity, material, and finish.
Injection molding typically costs between $3,000 and $100,000+, depending on mold size, complexity, and production needs. Simple molds may cost as little as $3,000, while complex, multi-cavity molds can exceed $50,000.
The primary cost is manufacturing the mold. While upfront costs can be high, injection molding becomes very economical for large production runs due to low per-part costs.
Key factors include mold size, complexity, mold type, cavity count, mold material, plastic resin, and production volume.
Higher production volumes reduce per-part cost by spreading mold costs across more parts.
Steel molds cost more upfront but last longer and lower per-part costs. Aluminum molds are cheaper initially but wear out faster and can’t be repaired.
Plastic resins cost $2 – $20 per pound. Specialty properties like heat resistance or food-grade compliance increase material costs.
Multi-cavity molds produce identical parts, while family molds produce related parts in one cycle, improving efficiency and reducing per-part cost.
Costs can be lowered by simplifying designs, reducing part size, limiting cosmetic features, and choosing cost-effective materials.
